• MB8S – 800V 0.5A SMD Bridge Rectifier

  • Single Phase SOIC-4 Surface Mount Rectifier

  • MB8S Datasheet, Stock and Pricing

Distributors

0 +

Part Numbers

0 +

Voltage (V)

0 +

MB8S Datasheet

The MB8S is a 0.5 A, 800 V single-phase SMD bridge rectifier in SOIC-4 package. Download the datasheet, compare prices and find stock from authorized distributors.

Download Datasheet

MB8S Datasheet

Price$50
TypeSoftware
ClientPrivate

The MB8S datasheet from onsemi covers all absolute maximum ratings, electrical characteristics, and package dimensions for the SOIC-4 SMD bridge rectifier.

MB8S Pinout

Price$100
TypeBusiness
ClientGlobal

MB8S uses a 4-lead SOIC (TO-269AA) package. AC input on pins 1 and 3; DC positive on pin 4; DC negative on pin 2.

MB8S Equivalent

Price$80
TypeApp
ClientPrivate

Cross-reference MB8S with DB107S, ABS10 and other 800 V SMD bridge rectifiers. All equivalents share the same SOIC-4 footprint.

MB8S Technical Overview

SPECIFICATIONS

The MB8S is a 0.5 A bridge rectifier family that achieves high surge current absorption within a very small 35 mm² footprint. Available in SOIC-4 / TO-269AA package from onsemi, Diotec, Fairchild and Yangzhou Yangjie.

MB8S800 V · 0.5 A · SOIC-4

MB8S Key Features

TECHNICAL

The MB8S surface mount bridge rectifier combines high surge capability with a compact SOIC-4 form factor. Rated 800 V VRRM with 35 A peak surge, it suits demanding small power supply designs.
